For tier-one structural steel erection, heavy utility infrastructure, and commercial roofing fit-outs, the Genie Z-62/40 stands out as an incredibly versatile access workhorse. Sourced directly through Pronto Access, this robust diesel knuckle boom lift features a four-wheel-drive system with full-time active oscillating axles, effortlessly maintaining traction on the most unstable jobsites. Its zero-tailswing and minimal front-arm swing design allow operators to swing and pivot the turntable safely within tight outdoor footprints, minimising the risk of onsite property damage. Buying from Pronto Access guarantees you receive a top-tier asset backed by a nationwide network of factory-trained mechanics, certified spare parts, and lifelong compliance tracking.
Overview
- 4WD Rough Terrain Grip: High-torque diesel engine couples with positive traction drive for up to 45% gradeability.
- 1.52m Articulating Jib: Offers a broad 135° vertical range to carefully adjust platform position around intricate infrastructure.
- Dual-Parallelogram Riser: Keeps the platform parallel to walls during vertical tracking without constant secondary adjustment.
- Foam-Filled Lug Tyres: Standard rough terrain tyres provide rock-solid ground contact across loose mud and rocks.
- Fully Proportional Joysticks: Ensure exceptionally smooth, steady operation for operator safety and confidence at full height.
- AS 1418.10 Compliant: Fully tested, certified, and delivered Australia-wide ready for immediate onsite deployment.
| Feature | Specification |
| Working Height | 20.87 m |
| Platform Height | 18.87 m |
| Horizontal Reach | 12.42 m |
| Up and Over Clearance | 7.80 m |
| Machine Width | 2.49 m |
Manufacturer’s warranty, brand new
Standard Metro Rates apply. Price will differ depending on size & volume—please fill out our form for an accurate freight quote.
Genie Z-62/40 Engine Powered Articulated Boom Lift
ENGINE POWERED KNUCKLE BOOM LIFTS FOR SALE
POA
The Genie Z-62/40, proudly supplied by Pronto Access, is a heavy-duty rough terrain articulating boom lift built for extreme outdoor construction and industrial tasks. Delivering a commanding 62ft platform height and an incredible 12.47m of horizontal outreach, it features the innovative Genie Fast Mastâ„¢ system to significantly accelerate vertical cycle times.
- Genie Fast Mastâ„¢ System: Allows operators to descend to ground level to grab tools and return to full height using a single boom function.
- Immersive Working Envelope: Offers unmatched horizontal reach alongside an up-and-over clearance height of 7.80 metres.
- Pronto Access Finance: Custom commercial asset finance options structured perfectly around your business cash flow.
20.87 m
Working Height
227 kg
Platform Capacity
10886 kg
Weight
For tier-one structural steel erection, heavy utility infrastructure, and commercial roofing fit-outs, the Genie Z-62/40 stands out as an incredibly versatile access workhorse. Sourced directly through Pronto Access, this robust diesel knuckle boom lift features a four-wheel-drive system with full-time active oscillating axles, effortlessly maintaining traction on the most unstable jobsites. Its zero-tailswing and minimal front-arm swing design allow operators to swing and pivot the turntable safely within tight outdoor footprints, minimising the risk of onsite property damage. Buying from Pronto Access guarantees you receive a top-tier asset backed by a nationwide network of factory-trained mechanics, certified spare parts, and lifelong compliance tracking.
Overview
- 4WD Rough Terrain Grip: High-torque diesel engine couples with positive traction drive for up to 45% gradeability.
- 1.52m Articulating Jib: Offers a broad 135° vertical range to carefully adjust platform position around intricate infrastructure.
- Dual-Parallelogram Riser: Keeps the platform parallel to walls during vertical tracking without constant secondary adjustment.
- Foam-Filled Lug Tyres: Standard rough terrain tyres provide rock-solid ground contact across loose mud and rocks.
- Fully Proportional Joysticks: Ensure exceptionally smooth, steady operation for operator safety and confidence at full height.
- AS 1418.10 Compliant: Fully tested, certified, and delivered Australia-wide ready for immediate onsite deployment.
| Feature | Specification |
| Working Height | 20.87 m |
| Platform Height | 18.87 m |
| Horizontal Reach | 12.42 m |
| Up and Over Clearance | 7.80 m |
| Machine Width | 2.49 m |
Manufacturer’s warranty, brand new
Standard Metro Rates apply. Price will differ depending on size & volume—please fill out our form for an accurate freight quote.
